pre-cleaners
PREPARE YOUR PLANT FOR BETTER CLEANING
Pre-cleaners efficiently remove large impurities and coarse particles from grains, ensuring smoother processing downstream. Built for reliability and ease of maintenance, they protect equipment while improving overall product quality.
Capacity: Up to 2 t/h
Seed cleaner of high-quality cleaning for free-floating seeds.
Capacity: Up to 30 t/h
Designed for pre-cleaning grain in storage.
Capacity: Up to 30 t/h
Screen cleaner for pre-cleaning, grading, and calibrating products.
Capacity: Up to 45 t/h
Silo separator ideal for pre-cleaning grain.
Capacity: Up to 150 t/h
Versatile mid-range pre-cleaning and barley dressing.
Capacity: Up to 200 t/h
Modular cleaner for high-purpose pre-cleaning.
Capacity: Up to 380 t/h
For pre-cleaning or fine cleaning, depending on configuration.
Capacity: Up to 75 t/h
Mid-range cleaner designed to master jobs at intake plants.
Capacity: Up to 50 t/h
Silo separator eminent for pre-cleaning of grain.
benifits of pre-cleaning
Pre-cleaning improves seed processing by removing large impurities such as straw, stones, dust, and plant debris before further cleaning. This protects processing equipment, improves efficiency, reduces wear and tear, and helps maintain better seed quality.
flow of a pre-cleaning
The seed lot is fed into the pre-cleaner, where aspiration removes light impurities such as dust, chaff, and empty seeds. The material then passes over a series of screens that separate oversized and undersized contaminants from the desired seed fraction. The cleaned product is discharged for further processing, while the removed impurities are collected separately.
Flow of pre-cleaner UP-A1-C4-D6-E20
faq on pre-cleaners
-
Air screen pre-cleaners are used to remove large and small impurities from incoming seed and grain to relieve the following machines and ready the product for storage.
We offer a comprehensive range of air screen pre-cleaning equipment for different purposes, among these for cleaning, sizing, precleaning, market grade cleaning and food grade cleaning. Capacities range from low-capacity machines suitable for grain storage facilities to high-capacity machines suitable for high intake plants.
-
All the Air screen pre-cleaners work with a combination of screens and airflow.
Firstly, a pre-suction catches light impurities and dust.
Secondly, a combination of screens, depending on capacity, separates large and small impurities. Screen sizes can be changed depending on product.
Lastly, a heavy after suction of the product catches even more light product with the same size as the main product.
-
Pre-cleaning is the first process after harvesting and is required to remove all unwanted product from the prime product. By removing the large and small impurities and dust, you prolong the storage time and reduce the risk of disease in the product. You also prevent blocking of silo outlets and further equipment in the process.
